Air Vapor Barrier/Waterproofing

Membrane Air Vapor Barrier:

GCP (Formerly Grace)



Grace Wall MembraneWall Membrane

Above Grade

Self-adhesive, rubberized asphalt/polyethylene waterproofing membrane for air and vapor barrier applications.

Available in:

  • 36″ x 75′ Rolls

 Product Data Sheet SDS  LEED


WB Primer

 WBPrimer

Perm-A-Barrier® WB Primer is a water-based primer which imparts an aggressive, high tack finish on the treated substrate.

Available in:

  • 1 Gallon pail
  • 5 Gallon pail

 Product Data Sheet SDS    LEED

Liquid Air Vapor Barrier:

GCP (Formerly Grace)



Perm-A-Barrier® NPL 10/ (NPL 10 LT – Winter)

 Fluid applied impermeable air and vapor barrier membrane

Perm-A-Barrier® NPL 10/NPL 10 LT is a fluid applied, one component, latex-based membrane that cures to form a resilient, monolithic, fully-bonded elastomeric sheet when applied to construction surfaces. Designed to satisfy the requirements of fire-rated assemblies, Perm-A-Barrier NPL 10/NPL 10 LT can be included in a wide variety of NFPA 285 compliant wall designs.
Perm-A-Barrier NPL 10/NPL 10 LT membrane is vapor impermeable and provides superior protection against the damaging effects of air and liquid water ingress on building structures. The product creates a solid barrier against air infiltration and exfiltration which minimizes energy loss from the structure and associated moisture related issues. Also impermeable to liquid water, Perm-A-Barrier NPL 10/NPL 10 LT acts as a water drainage plane.

Advantages:

– Fire Resistant-meets NFPA285 – Plasticizer, Phthalate and Halogen-free
– Air Tight – Single Component
– Fully Bonded – Seamless
– Strong Adhesion

Product Data Sheet  SDS    LEED




Perm-A-Barrier® VPL

Fluid applied vapor permeable air barrier membrane

Perm-A-Barrier® VPL is a fluid applied, one component, acrylic membrane that cures to form a resilient, monolithic, fully bonded elastomeric sheet when applied to construction surfaces. Perm-A-Barrier® VPL membrane provides superior protection against the damaging effects of air and liquid water ingress on building structures. The product creates a solid barrier against air infiltration and exfiltration, which minimizes associated energy loss and condensation problems.
Perm-A-Barrier® VPL membrane is vapor permeable for wall assemblies requiring this “breathable” characteristic. As a vapor permeable membrane, it permits the transfusion of water vapor that may otherwise condense in the wall structure; but is impermeable to liquid water, which allows the material to act as a water drainage plain. The Volatile Organic Compound (VOC) content of Perm-A-Barrier® VPL membrane is less than 30 g/L.

Advantages:

– Fire Resistant -meets NFPA 285 – Plasticizer, Phthalate and Halogen-free
– Air Tight – Vapor Permeable
– Single Component – Fully Bonded
– Damp Surface Tolerant – Strong Adhesion

Product Data Sheet  SDS   LEED


Grace Perm-A-Barrier Detail MembranePerm-A-Barrier® Detail Membrane

Ideal for protecting and sealing critical areas of the building superstructure from the damaging effects of the elements. By minimizing air and water vapor flow through the building exterior at transition areas, Perm-A-Barrier Detail Membrane seals transition and detail areas to provide a continuous air barrier and Prevents premature deterioration of the building envelope. Perm-A-Barrier Detail Membrane is part of the full Perm-A-Barrier system for commercial applications.

Available in:

  • 6″ x 75′ Rolls
  • 9″ x 75′ Rolls
  • 12″ x 75′ Rolls

 Product Data Sheet  SDS  LEED


Perm-A-Barrier® S100 Sealant

One part neutral curing, ultra low modulus silicone sealant

Perm-A-Barrier® S100 Sealant is a one part neutral curing, ultra low modulus silicone sealant that reacts with atmospheric moisture to form a durable and flexible building sealant. S100 sealant is designed for a variety of uses with GCP Applied Technologies’ air and weather barrier systems. The Volatile Organic Compound (VOC) content is <100 g/L.

Product Data Sheet   SDS  LEED

R-GUARD



Prosoco Spray Wrap MVPSpray Wrap MVP

PROSOCO R-GUARD® Spray Wrap MVP is a fluid-applied air and water-resistive barrier that stops air and water leakage in cavity wall, masonry veneer construction, as well as in stucco, EIFS and most other building wall assemblies.

Available in:

  • 5 Gallon pail

 Product Data Sheet  SDS   LEED


Prosoco Vapor Barrier VBVB (Vapor Barrier)

PROSOCO R-GUARD® VB is developed to maximize wall R-values by preventing the unwanted movement of water and air through building envelopes. PROSOCO R-GUARD® VB is a fluid-applied air and water-resistive barrier that stops air and water leakage in cavity wall, masonry veneer construction, as well as in stucco, EIFS and most other building wall assemblies.

Available in:

  • 5 Gallon pail

 Product Data Sheet  SDS   LEED


Prosoco FastFlashfastflash-rg3-ff-arch2-1_webFastFlash

PROSOCO R-GUARD® FastFlash® is a gun-grade waterproofing, adhesive and detailing compound that combines the best of silicone and polyurethane properties.

Available in:

  • Quart tube (29 oz)

 Product Data Sheet  SDS   LEED


Prosoco Joint & Seam FillerJoint & Seam Filler

PROSOCO R-GUARD® Joint & Seam Filler is a high modulus, gun-grade, crack and joint filler, adhesive and detailing compound that combines the best of silicone and polyurethane properties.

Available in:

  • Quart tube (29 oz)

 Product Data Sheet  SDS   LEED



Window Tape:

Vycor® Plus

Provides superior protection against water, air and moisture infiltration in window and door openings, corner boards, under stucco finishes, masonry walls and other flashing areas. It is designed to work in severe winter climates, milder climates, and in coastal areas where wind driven rain is common. It should not be used on roofs. Grace Vycor® Plus is ideal for sealing joints, seams, holes, and other unwanted openings in wall sheathing systems. It is 25 mil thick and compatible with wood, plywood, oriented strand board, concrete and masonry and fully adheres to the substrate to prevent water from passing through and into the substrate.

Available in:

  • 4″ x 75′ Rolls
  • 6″ x 75′ Rolls
  • 9″ x 75′ Rolls

 Product Data Sheet SDS  LEED

Dampproofing:

BASF MasterSeal 615/700B Semi MasticMasterSeal 615/700B Semi-Mastic

(Brush or Spray)

Is a cold-applied water-based emulsified-asphalt dampproofing and vapor-retarding coating for use on “green” or slightly damp surfaces. MasterSeal 615/700B is reinforced with short fibers for application by brush or spray.

Available in:

  • 5 Gallon pail

 Product Data Sheet SDS

Waterproofing:

Bituthene® 4000 System

Below Grade

Self-adhesive 60 mil HDPE waterproofing membrane with super tacky compound for use with patented, water-based System 4000 Surface Conditioner (included with roll).

Available in:

  • 36″ x 67′ Rolls

 Product Data Sheet  SDS LEED


Bituthene® Mastic

(for both Above Grade and Below Grade Applications)

A rubberized asphalt-based mastic. It has excellent adhesion to structural concrete, masonry and wood and is designed to seal terminations, edges of patches, and overlaps in detail areas. It is an integral part of the Bituthene Waterproofing System, though it should not be used as a primary waterproofing material.

Available in:

  • Quart tube

 Product Data Sheet SDS    LEED
